The id(s) for emsiles = [Li] theory{dft} xc{lda} basis{Def2-TZVPD} solvation_type{COSMO} ^{0} mult{2} are: 66907
Use id=% instead of esmiles to print other entries.
mformula = Li1
iupac = lithium doublet radical
PubChem = 3028194
PubChem LCSS = 3028194
cas = 7439-93-2
kegg = C15473 D08133
synonyms = 7439-93-2; Li; Lithium; litio; CHEBI:30145; MFCD00134051; Litium; Lithium, 99+%, granular, dry; 3Li; monolithium; Lithium standard solution, for AAS, 1 mg-ml Li in 2% HCl; Hydrure de lithium [French]; Lithium ribbon; Lithium rod; HSDB 549; Lithium granules; EINECS 231-484-3; UN1414; UN2805; Normothymin-E (TN); Epitope ID:114079; Lithium, 99%, low sodium; Lithium, 99%, high sodium; CHEMBL2146126; DTXSID5036761; 7321AH; AKOS015833388; AKOS015902481; Lithium wire, 3.2mm (0.125in) dia; Lithium granules, 1-6mm (0.04-0.2in); Lithium, granular, 99% trace metals basis; FT-0627905; C15473; D08133; EC 231-484-3; Lithium hydride [UN1414] [Dangerous when wet]; Lithium, shot, 99%, 4-16 mesh, in mineral oil; Lithium, wire, diam. 3.2 mm, in mineral oil, >=98%; Lithium, ~25 wt % dispersion in mineral oil, high sodium; Lithium, AAS standard solution, Specpure?, Li 1000?g/ml; Lithium, ingot, diam. 5.7 cm, 99.9% trace metals basis; Lithium, rod, diam. 12.7 mm, 99.9% trace metals basis; Lithium foil, 0.75mm (0.03in) thick x 19mm (0.75in) wide; Lithium hydride, fused solid [UN2805] [Dangerous when wet]; Lithium ingot, 5.7cm (2.2in) dia x 8.6cm (3.4in) long; Lithium, Oil based standard solution, Specpure, Li 5000g/g; Lithium, plasma standard solution, Specpure?, Li 10,000?g/ml; Lithium, plasma standard solution, Specpure?, Li 1000?g/ml; Lithium, rod, 12.7 mm diameter, length 165 mm, purity 99%; Lithium, rod, 12.7 mm diameter, length 200 mm, purity 99%; Lithium, foil, 25x100mm, thickness 0.6mm, as rolled, 99.9%; Lithium, Oil based standard solution, Specpure(R), Li 1000?g/g; Lithium, foil, thickness 0.6 mm, size 25 x 300 mm, purity 99.9%; Lithium, Ion chromatography standard solution, Specpure, Li+ 1000?g/ml; Lithium, wire (in mineral oil), diam. 3.2 mm, 99.9% trace metals basis; Lithium, foil, not light tested, 38x200mm, thickness 0.20mm, as rolled, 99.9%; Lithium, foil, not light tested, 38x500mm, thickness 0.20mm, as rolled, 99.9%; Lithium, foil, not light tested, 45x200mm, thickness 0.12mm, as rolled, 99.9%; Lithium, granular, 4-10 mesh particle size, high sodium, 99% (metals basis); Lithium, ribbon, thickness x W 0.38 mm x 23 mm, 99.9% trace metals basis; Lithium, ribbon, thickness x W 0.75 mm x 19 mm, 99.9% trace metals basis; Lithium, ribbon, thickness x W 0.75 mm x 45 mm, 99.9% trace metals basis; Lithium, ribbon, thickness x W 1.5 mm x 100 mm, 99.9% trace metals basis
Search Links to Other Online Resources (may not be available):
- Google Structure Search
- EPA CompTox Database
- Chemical Entities of Biological Interest (ChEBI)
- NIH ChemIDplus - A TOXNET DATABASE
- The Human Metabolome Database (HMDB)
- OECD eChemPortal
- Google Scholar
+==================================================+
|| Molecular Calculation ||
+==================================================+
Id = 66907
NWOutput = Link to NWChem Output (download)
Datafiles:
homo-alpha.cube-869921-2021-11-21-9:56:31 (download)
homo-beta.cube-869921-2021-11-21-9:56:31 (download)
lumo-alpha.cube-869921-2021-11-21-9:56:31 (download)
lumo-beta.cube-869921-2021-11-21-9:56:31 (download)
mo_orbital_nwchemarrows-2021-12-9-12-15-135662.out-94259-2021-12-9-18:37:2 (download)
image_resset: api/image_reset/66907
Calculation performed by Eric Bylaska - constance.pnl.gov
Numbers of cpus used for calculation = 48
Calculation walltime = 35.500000 seconds (0 days 0 hours 0 minutes 35 seconds)
+----------------+
| Energetic Data |
+----------------+
Id = 66907
iupac = lithium doublet radical
mformula = Li1
inchi = InChI=1S/Li
inchikey = WHXSMMKQMYFTQS-UHFFFAOYSA-N
esmiles = [Li] theory{dft} xc{lda} basis{Def2-TZVPD} solvation_type{COSMO} ^{0} mult{2}
calculation_type = ovc
theory = dft
xc = lda
basis = Def2-TZVPD
charge,mult = 0 2
energy = -7.343802 Hartrees
enthalpy correct.= 0.002359 Hartrees
entropy = 31.784 cal/mol-K
solvation energy = 1.503 kcal/mol solvation_type = COSMO
Sitkoff cavity dispersion = 1.503 kcal/mol
Honig cavity dispersion = 3.217 kcal/mol
ASA solvent accesible surface area = 128.680 Angstrom2
ASA solvent accesible volume = 137.258 Angstrom3
+-----------------+
| Structural Data |
+-----------------+
JSmol: an open-source HTML5 viewer for chemical structures in 3D
Number of Atoms = 1
Units are Angstrom for bonds and degrees for angles
Type I J K L M Value
----------- ----- ----- ----- ----- ----- ----------
+-----------------+
| Eigenvalue Data |
+-----------------+
Id = 66907
iupac = lithium doublet radical
mformula = Li1
InChI = InChI=1S/Li
smiles = [Li]
esmiles = [Li] theory{dft} xc{lda} basis{Def2-TZVPD} solvation_type{COSMO} ^{0} mult{2}
theory = dft
xc = lda
basis = Def2-TZVPD
charge = 0
mult = 2
solvation_type = COSMO
twirl webpage = TwirlMol Link
image webpage = GIF Image Link
Unrestricted Eigevalue Spectra
alpha beta
---------- 35.87 eV ---------- 36.49 eV
--- -- --- --- -- ---
----------
-- -- -- - --- -- ---
--- -- ---LUMO= -1.28 eV --- -- ---
HOMO= -3.16 eV++++++++++ ----------LUMO= -2.09 eV
-51.01 eV++++++++++ HOMO= -50.80 eV++++++++++
spin eig occ ---------------------------- alpha -51.01 1.00 alpha -3.16 1.00 alpha -1.28 0.00 alpha -1.28 0.00 alpha -1.28 0.00 alpha 1.09 0.00 alpha 1.09 0.00 alpha 1.09 0.00 alpha 1.43 0.00 alpha 12.60 0.00 alpha 12.60 0.00 alpha 12.60 0.00 alpha 35.87 0.00 beta -50.80 1.00 beta -2.09 0.00 beta -0.52 0.00 beta -0.52 0.00 beta -0.52 0.00 beta 1.56 0.00 beta 1.56 0.00 beta 1.56 0.00 beta 2.07 0.00 beta 13.37 0.00 beta 13.37 0.00 beta 13.37 0.00 beta 36.49 0.00
+----------------------------------------+ | Vibrational Density of States Analysis | +----------------------------------------+ Total number of frequencies = 3 Total number of negative frequencies = 0 Number of lowest frequencies = 0 (frequency threshold = 500 ) Exact dos norm = -3.000 Generating vibrational DOS Generating model vibrational DOS to have a proper norm 10.00 0.00 0.00 0.00 50.00 0.00 0.00 0.00 100.00 0.00 0.00 0.00 Writing vibrational density of states (DOS) to vdos.dat Writing model vibrational density of states (DOS_FIXED) to vdos-model.dat Temperature= 298.15 zero-point correction to energy = 0.000 kcal/mol ( 0.000000) vibrational contribution to enthalpy correction = 0.000 kcal/mol ( 0.000000) vibrational contribution to Entropy = 0.000 cal/mol-k hindered rotor enthalpy correction = 0.000 kcal/mol ( 0.000000) hindered rotor entropy correction = 0.000 cal/mol-k
DOS sigma = 10.000000
- vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- model vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- model vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- original gas Energy = -7.343802 (-4608.305 kcal/mol)
- original gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- unajusted DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- model DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- original gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- unajusted DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- model DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- original gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- unadjusted DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- model DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- original sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- unadjusted DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- model DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
DOS sigma = 50.000000
- vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- model vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- model vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- original gas Energy = -7.343802 (-4608.305 kcal/mol)
- original gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- unajusted DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- model DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- original gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- unajusted DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- model DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- original gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- unadjusted DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- model DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- original sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- unadjusted DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- model DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
DOS sigma = 100.000000
- vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- model vibrational DOS enthalpy correction = 0.000000 kcal/mol ( 0.000 kcal/mol)
- vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- model vibrational DOS Entropy = 0.000000 ( 0.000 cal/mol-k)
- original gas Energy = -7.343802 (-4608.305 kcal/mol)
- original gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- unajusted DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- model DOS gas Enthalpy = -7.341443 (-4606.825 kcal/mol, delta= 0.000)
- original gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- unajusted DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- model DOS gas Entropy = 0.000051 ( 31.784 cal/mol-k,delta= 0.000)
- original gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- unadjusted DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- model DOS gas Free Energy = -7.356545 (-4616.302 kcal/mol, delta= 0.000)
- original sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- unadjusted DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
- model DOS sol Free Energy = -7.354149 (-4614.798 kcal/mol)
Normal Mode Frequency (cm-1) IR Intensity (arbitrary)
----------- ---------------- ------------------------
1 0.000 0.000
2 0.000 0.000
3 0.000 0.000
No Hindered Rotor Data
+-------------------------------------+
| Reactions Contained in the Database |
+-------------------------------------+
Reactions Containing INCHIKEY = WHXSMMKQMYFTQS-UHFFFAOYSA-N
Reactionid Erxn(gas) Hrxn(gas) Grxn(gas) delta_Solv Grxn(aq) ReactionType Reaction
12909 58.283 57.156 52.082 19.858 71.940 AB --> A + B "[LiH] --> [Li] + [H]"
12908 58.283 57.156 52.082 19.858 71.940 AB --> A + B "[LiH] --> [Li] + [H]"
9252 20.279 21.167 16.311 6.041 22.351 AB --> A + B "[Li][Li] xc{b3lyp} basis{Def2-TZVPD} --> 2 [Li] mult{2} xc{b3lyp} basis{Def2-TZVPD}"
9231 20.060 20.948 16.097 5.629 21.726 AB --> A + B "[Li][Li] xc{blyp} basis{Def2-TZVPD} --> 2 [Li] mult{2} xc{blyp} basis{Def2-TZVPD}"
9214 18.946 19.834 14.989 6.448 21.437 AB --> A + B "[Li][Li] xc{pbe0} basis{Def2-TZVPD} --> 2 [Li] mult{2} xc{pbe0} basis{Def2-TZVPD}"
9201 19.691 20.579 15.735 6.048 21.783 AB --> A + B "[Li][Li] xc{pbe} basis{Def2-TZVPD} --> 2 [Li] mult{2} xc{pbe} basis{Def2-TZVPD}"
9179 23.267 24.154 19.301 5.990 25.291 AB --> A + B "[Li][Li] xc{lda} basis{Def2-TZVPD} --> 2 [Li] mult{2} xc{lda} basis{Def2-TZVPD}"
9160 22.183 23.071 18.210 0.000 18.210 AB --> A + B "[Li][Li] theory{pspw4} xc{b3lyp} --> 2 [Li] mult{2} theory{pspw4} xc{b3lyp}"
9159 21.902 22.790 17.928 0.000 17.928 AB --> A + B "[Li][Li] theory{pspw} xc{b3lyp} --> 2 [Li] mult{2} theory{pspw} xc{b3lyp}"
9123 22.810 23.697 18.836 0.000 18.836 AB --> A + B "[Li][Li] theory{pspw4} xc{blyp} --> 2 [Li] mult{2} theory{pspw4} xc{blyp}"
9122 22.824 23.712 18.851 0.000 18.851 AB --> A + B "[Li][Li] theory{pspw} xc{blyp} --> 2 [Li] mult{2} theory{pspw} xc{blyp}"
9121 20.460 21.347 16.486 5.462 21.948 AB --> A + B "[Li][Li] xc{blyp} --> 2 [Li] mult{2} xc{blyp}"
9084 18.874 19.761 14.921 0.000 14.921 AB --> A + B "[Li][Li] theory{pspw4} xc{pbe0} --> 2 [Li] mult{2} theory{pspw4} xc{pbe0}"
9083 18.548 19.436 14.580 0.000 14.580 AB --> A + B "[Li][Li] theory{pspw} xc{pbe0} --> 2 [Li] mult{2} theory{pspw} xc{pbe0}"
9082 19.244 20.132 15.283 6.419 21.702 AB --> A + B "[Li][Li] xc{pbe0} --> 2 [Li] mult{2} xc{pbe0}"
9040 19.755 20.642 15.794 0.000 15.794 AB --> A + B "[Li][Li] theory{pspw} xc{pbe} --> 2 [Li] mult{2} theory{pspw} xc{pbe}"
9039 19.963 20.851 16.002 5.979 21.980 AB --> A + B "[Li][Li] xc{pbe} --> 2 [Li] mult{2} xc{pbe}"
8992 23.650 24.537 19.678 0.000 19.678 AB --> A + B "[Li][Li] theory{pspw4} xc{lda} --> 2 [Li] mult{2} theory{pspw4} xc{lda}"
8991 23.667 24.555 19.696 0.000 19.696 AB --> A + B "[Li][Li] theory{pspw} xc{lda} --> 2 [Li] mult{2} theory{pspw} xc{lda}"
8990 23.568 24.456 19.595 5.842 25.437 AB --> A + B "[Li][Li] xc{lda} --> 2 [Li] mult{2} xc{lda}"
8986 20.705 21.593 16.731 5.922 22.653 AB --> A + B "[Li][Li] xc{b3lyp} --> 2 [Li] mult{2} xc{b3lyp}"
8970 19.738 20.626 15.778 0.000 15.778 AB --> A + B "[Li][Li] theory{pspw4} xc{pbe} --> 2 [Li] mult{2} theory{pspw4} xc{pbe}"
